Wire Harness Circular Labeling Machine

  • Model:KS-L115C
  • Brand:KINGSING
  • Voltage:220V (Can be customized)
  • Function:
  • Price:

This is our latest wire circular labeling machine, which is not only suitable for round wire, but also for pair twisted wire and wire harness composed of multiple wires. The operator only need to simply put the wire into the working position,then it can automatically wrap the label onto the wire without rotating the wire itself.

The machine can be equipped with an optional wire label printer, and we can supply the raw materials of wire labels, the label size can be customized according to customer requirements.

KINGSING

Download: (1) (2)

Label Printer: optional

Available Wire Size: 3~12mm

Label Width: 5~40mm

Label Length: 10~100mm

Max. Label Roll OD: 240mm

Labeling Accuracy: ±0.2mm

Capacity: 1000~1500pcs/hour

Air Source: 0.4~0.6Mpa

Power Rating: 250W

Power Supply: 220V 50/60Hz

Net. Weight: 86kg

Dimension: 580×680×1000mm

Note: Conforms to the relevant CE directives on machine safety and electromagnetic compatibility.
