Sponge Strip Folding and Labeling Machine

  • Model:KS-L902
  • Brand:KINGSING
  • Voltage:220V (Can be customized)
  • Function:
  • Price:

Features:

1. Accurate positioning of servo motor;

2. The German SICK label electric eye quickly senses the sponge gap to complete the labeling and identification;

3. Reasonable mechanical structure design ensures smooth and stable labeling; humanized perfect structure design;

4. It is easy to apply and can be adjusted in a large range to realize half-fold labeling on wire and harness products of different specifications;

5. There is no need to twist the screw to adjust the machine, just input the label size and wire diameter size directly on the display screen;

6. There is a fine-tuning button for the tolerance equipment of the label, just press it, the equipment has a memory group function, and the performance is quite stable;

7. Improve production efficiency, solve the advantages of slow manual labeling, insufficient accuracy, personnel changes and high labor costs;

8. Numerical control adjustment, stable performance, the machine display comes with manual, which is convenient for factory operators to read at any time.


Download: (1) (2)

Configuration standard positioning ruler: 200MM (customized beyond the scope)

Accuracy: ±0.3 (excluding product, sponge error)

Maximum label roll outer diameter: 240mm

Maximum inner diameter of label roll: 76mm

Machine weight: about 86Kg

Power supply: 220V/50HZ

Power: 0.25KW

Air pressure: 4-6bar

Operating environment temperature: 5~40℃

Relative humidity: (20-90) %RH

Machine size (L X W X H): 580mmX680mmX1000mm

Speed: 800-1200pcs/H (depending on label size and manual operation speed)

Applicable size: length 40mm~160mm(customization beyond the scope)

     width 5mm~45mm (customization beyond the scope)

Note: Conforms to the relevant CE directives on machine safety and electromagnetic compatibility.
