This is a motor driven hot stamp wire marking machine, the characters are engraved on the disc, and the print content can be modified by rotating the disc. Supported characters are: ABCDEFGHIJKLMNOPQRSTUVWXYZ+-/· 0123456789, including a space.
The heating temperature of the character mold can be set freely. The operator only needs to put the wire into the fixture and step on the pedal switch, then the pre-set characters will be scalded to the wire insulation automatically.
The printed color is determined by the color of the hot transfer strap (White or Black), you can choose the appropriate ribbon color according to the color of the wire. The size of the character is determined by the mold, we can customize the appropriate character size according to the wire diameter. The maximum number of characters that can be printed can also be customized on demand.
Available Cable Diameter: Φ2~16mm
Character Size: 1.0~2.4mm (Customized)
Number of Characters: 7~50 (Customized)
Power Rating: 80W
Power Supply: 220V/50Hz (110V can be customized)
Net Weight: 20Kg
