Automatic Stretch Wrapping Machine

  • Model:KS-FB Series
  • Brand:KINGSING
  • Voltage:220V (Can be customized)
  • Function:Film Wrapping
  • Price:

This explosion-proof wrapping machine is specifically designed for the safe packaging of hazardous chemical products, featuring multiple safety mechanisms to ensure reliable operation in flammable and explosive environments. It is ideal for use in industries such as chemicals, pharmaceuticals, and petrochemicals, where safety is a top priority.

  1. Explosion-Proof Electrical Control Box: The system is equipped with an explosion-proof electrical control box, increasing the equipment’s protection level and preventing sparks or excessive heat under normal operation or overload conditions, ensuring safe and reliable performance.

  2. Explosion-Proof Motor: The machine is fitted with an explosion-proof motor, eliminating the risk of igniting explosive mixtures during operation. This makes it particularly suitable for use in hazardous chemical environments where safety is paramount.

  3. Programmable Logic Controller (PLC): The machine supports PLC programming, allowing users to adjust the number of wrapping layers and speed to match the size and characteristics of the cargo. This enhances process flexibility and ensures precise, safe wrapping operations.

  4. Optical Switch for Automatic Height Detection: An advanced optical switch system automatically detects the height of the load, enabling accurate wrapping adjustments. This minimizes the need for manual intervention, reducing the risk of human error and improving overall safety.

  5. Durable and Stable Construction: Built with a solid, durable structure, the machine is designed for long-term, continuous operation in demanding environments. This ensures high stability, reliability, and a long operational lifespan.

  6. Safety-Designed Film Replacement: The machine incorporates a safe and efficient film replacement mechanism, facilitating quick and easy film changes while avoiding direct operator contact, thus reducing the risk of accidents during maintenance.

Download: (1)
ModelTurntable DiameterMachine WeightMachine Dimensions
KS-FB12001200mmApprox. 350kg2200×1200×2650mm
KS-FB15001500mmApprox. 380kg2450×1500×2650mm
KS-FB16501650mmApprox. 400kg2600×1650×2650mm
KS-FB18001800mmApprox. 450kg2800×1800×2650mm
KS-FB20002000mmApprox. 600kg3000×2000×2650mm
KS-FB22002200mmApprox. 650kg3200×2200×2650mm
KS-FB24002400mmApprox. 750kg3400×2400×2650mm
  • Max Wrapping Height: 2200 mm

  • Turntable Height: 80 mm

  • Load Capacity: Approx. 2 tons (Optional 3-ton models available)

  • Power: 1.5 kW

  • Voltage: Single Phase 220V / 50Hz

  • Turntable Speed: 0–12 rpm

  • Optional Functions: Automatic Weighing, Top Platen, Ramp
